Quick Details
- Light Source: LED
- Item Type: Tube Lights
- LED Light Source: SMD2835
- Warranty(Years): 3
- Input Voltage(V): 85-265
- Lamp Power(W): 36
- Lamp Luminous Flux(lm): 3600
- Lamp Luminous Efficiency(lm/w): 100
- CRI (Ra>): 80
- Color Temperature(CCT): Cool White
- Working Temperature(℃): -40 - 55
- Working Lifetime(Hour): 50000
- Lamp Body Material: PVC
- IP Rating: IP65
- Certification: CE, EMC, LVD, RoHS
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: Brightness
- Model Number: PM01L-36w
- Product Name: Led linear light
- Brand Of Chip: Epistar 2835
- Luminous: 3600 LM
- Color Temperature: 2700~6500K
- CRI: Ra≥80
- Beam Angle: 110°
- size: 1200*113*45mm
- Material: PVC+PMMA
- other Length: 300mm;600mm;Customized
- other Power: 9w;18w;
Packaging & Delivery
Packaging Details: | 8pcs/Carton:1320*290*265cm NW:16kg GW:19kg |
---|
Advantages:
•Wide input voltage rangeAC85-265V;
•High lumens 100LM/W, high level of dustproof and waterproof IP65.
•Streamline design, not easily stained with dust, dust free and easy maintenance
•Top-grade PVC body and stainless steel mounting clips guarantee excellent Corrosion Proof performance.
•50% energy saving than traditional lighting.
•Best design for low LED light decay & long life time, working hours up to 50000 hours,3 years warranty.
•Strictly designed for waterproof, dust proof and corrosion proof performance
•Perfect heat dissipation and low operation temperature
•Extremely low maintenance, safety and cost aspect
•Can customized product:24V DC, infrared induction,emergency battery,according to the request custom-made, the light body without chip and driver
Item code | Power | Power Factor | Luminous Efficiency | Luminous Flux | CRI | Operation Temperature | IP Rating | Life | Dimension(mm) |
PM01L-36W | 36W | 0.96 | 100 lm/w | 3600Lm | Ra>80 | -40℃-+55℃ | IP65 | 50000H | 1205*113*45 |
BC-L36 explosion | 36W | 0.96 | 100 lm/w | 3600Lm | Ra>80 | -40℃-+55℃ | IP65 | 50000H | 1205*113*45 |
PM01L-18W | 18w | 0.96 | 100 lm/w | 1800LM | Ra>80 | -40℃-+55℃ | IP65 | 50000H | 607*113*45 |
PM01L-9w | 9w | 0.96 | 100lm/w | 900lm | Ra>80 | -40℃-+55℃ | IP65 | 50000H | 307*113*45 |
Specification | |
Power: | 36w |
Material: | PVC+PMMA |
Type Of Chip: | 2835 LED Chip |
Brand Of Chip: | Epistar |
Luminous: | 3600 LM |
Color Temperature: | 2700~6500K |
CRI: | Ra≥80 |
Beam Angle: | 110° |
Total Harmonic Distortion(THD): | <15% |
PF: | >0.96 |
Working Life: | ≥ 50000hours |
Warranty: | 3 years |
Dimensions | |
Finishing Color: | White |
Wire connection: | Brown;Blue |
Shape: | Rectangle |
Weight: | 1.96 Kg |
Size: | 1205 x 113 x 45mm |
Inner Box Size: | 1pcs/inner box , 1290*135*55mm |
Package Size: | Box size: 1320*290*265mm,8pcs/carton; |
Work Environment | |
Input Voltage: | AC85-260V/50-60Hz |
OperatingTemperature: | -40~+55℃ |
Application | |
Application | Used for subway station,factory,parking garage,tunnel, basement,supermarket,restaurants,hospital,office,school, storages and other indoor public place etc. |
